Machine Characteristics

Basic configuration

  • Manual sheet feeding
  • Coating unit with 3-rollers application system.
  • Air knife for reliable thin sheets run through the machine.
  • IR heating unit including Hot Air fans helps for better flow of the UV varnish before curing to reach uniform coating layer, or to dry the coated layer when using the AQ varnish.
  • UV curing system, with electronic power supply.
  • Fixed delivery desk.
  • Wheels for easy movement of the machine

Available options

No options available

Technical specifications

Parameter Value
5-20 m/min
Max sheet size
36 × 72 cm
Paper weight
115-350 g/m²
Machine dimensions
190 × 77 × 108 cm
Min. sheet dimensions
15 × 20 cm
Varnish type
UV varnish, viscosity 30-65 s
Application quantity
4-15 g/m²
Time of UV lamp activation
Cca 3 min.
UV lamp power
3 kVA
Air supply
Min. 6 bar
Consumption of compressed air
Max. 81 l/min
Power supply
3,5 kVA
Machine weight
207 kg
Parametr Hodnota
Min. rozměry archů
15 × 20 cm
Druh laku
UV lak, viskozita 30-65 s
Množství aplikace
4-15 g/m²
Čas aktivace UV lampy
Cca 3 min.
Výkon UV lampy
3 kVA
Vzduchová přípojka
Min. 6 bar
Spotřeba tlakového vzduchu
Max. 81 l/min
Zdroj napájení
3,5 kVA
Hmotnost stroje
207 kg

Custom-built solutions

Possibility of individual machine modification based on specific requirements

* Technical parameters of our products are subject to change without prior notice.
* Product pictures/videos may show additional options not included in the standard delivery.
